10 Ton Hydraulic Type Cable Drum Lifting Jack

Underground Cable Drum Uplifting Jack Hydraulic Bottle Jack Type (10 Ton Capacity)

The Underground Cable Drum Uplifting Jack is a heavy-duty lifting device designed for safe and efficient lifting of cable drums during underground cable-laying operations. It is widely used at project sites to raise and support heavy cable drums for smooth cable paying-out and controlled handling.

This jack system is based on a robust hydraulic bottle jack mechanism and is mounted on a strong fabricated steel frame to ensure stability and reliability under high load conditions. It enables easy lifting of heavy cable drums with minimal manual effort, improving operational safety and productivity at site.

With a rated lifting capacity of 10 tons, this uplifting jack is suitable for handling large and heavy power cable drums used in HT and LT underground cable installations. The adjustable lifting arrangement allows it to accommodate a wide range of drum sizes.

The jack is designed to accept cable drum center heights ranging from 600 mm to 1800 mm, making it highly versatile for different drum diameters and site requirements.

Key Applications:

• Lifting and supporting cable drums for underground cable laying

• Controlled cable paying-out operations

• Handling heavy HT and LT power cable drums

• Utility, power distribution, and infrastructure projects

Features:

• Heavy-duty hydraulic bottle jack system

• High lifting capacity: 10 tons

• Strong fabricated steel frame for site stability

• Adjustable height to suit various drum sizes

• Acceptable cable drum center height: 600 mm to 1800 mm

• Easy operation with minimal manual effort

• Designed for rugged field and construction site conditions
