Screw Type Cable Drum Lifting Jack

Underground Cable Drum Uplifting Jack Screw Type (10 Ton Capacity)

The Screw Type Cable Drum Uplifting Jack is a robust and reliable mechanical lifting device designed for safe handling and uplifting of heavy cable drums during underground cable-laying operations. It is widely used at project sites for raising and supporting cable drums to enable smooth and controlled cable paying-out.

This jack operates on a heavy-duty screw mechanism, offering precise height adjustment and stable load holding without hydraulic components. The strong fabricated steel body and high-strength screw ensure durability, long service life, and dependable performance under demanding site conditions.

With a rated lifting capacity of 10 tons, this screw type jack is suitable for handling heavy HT and LT power cable drums used in underground cable installation projects.

The jack is designed to work efficiently within a recommended cable drum center height range of 900 mm to 1000 mm, ensuring optimal stability and safe load distribution. The maximum full open height of the screw jack is 1200 mm.

To ensure smooth operation and reduce rotational friction under heavy load, the jack is equipped with a thrust bearing for free and easy rotation, which minimizes manual effort and wear on components.

For safety and long service life, it is strongly recommended not to use the jack at its full open height. Operating within the specified working height range ensures better stability, load control, and reduced stress on the screw and structural components.

Key Applications:

• Lifting and supporting cable drums for underground cable laying

• Controlled cable paying-out operations

• Handling heavy HT and LT power cable drums

• Utility, power distribution, and infrastructure projects

Features:

• Heavy-duty screw type mechanical lifting system

• High lifting capacity: 10 tons

• Strong fabricated steel construction

• Smooth operation with thrust bearing for free rotation

• Recommended cable drum center height: 900 mm to 1000 mm

• Maximum full open height: 1200 mm

• Precise height adjustment and stable load holding

• Rugged design for construction and site conditions

Safety Note:

• Do not operate the jack at full open height.

• Always use within the recommended working height range (9001000 mm) for safe and stable operation.
